Pepperl+Fuchs Khd2-rs1/Ex2 Switch Amplifier 20Ma 415Nf 250Vac 65°C

Pepperl+Fuchs Khd2-rs1/Ex2 Switch Amplifier 20Ma 415Nf 250Vac 65°C
Pepperl+Fuchs
K-serie
Khd2-rs1/Ex2
Part.No: 19281S
Control Circuit [Eex Ia] Ii C
Ptb Nr.Ex-89.C.2073
Namur Din 19234
Operating Values:
Uo Ca.8V
Jk Ca.8Ma
Maximum Values:
Uo: 12,7V
Jk: 20Ma
P: 63,5Mw
[Eex Ia] Iic:
Ca: 415Nf
La: 2Mh
Output:
U: 250Vac
J: 2A
Cos ϕ: 0.7
U: 30Vdc
Supply 11-12: 24Vdc ±15% 10%
Ambient Temperature: 65°C
Weight: 170 Gm
