Pepperl+fuchs Kfd2-sr2-ex1.w Switch Amplifier K-system 20–30vdc 2a

Pepperl+fuchs Kfd2-sr2-ex1.w Switch Amplifier K-system 20–30vdc 2a
Pepperl+fuchs
K-system
Kfd2-sr2-ex1.w
Part No: 132958
Ii (1) G D [eex Ia] Iic
Ii 3 G Ex Na Nc Iic T4
I (3) G [ex Ic] Iic
Ii (3) G [ex Nl.] Iic
Ptb 00 Atex 2080
Tuv 99 Atex 1493 X
Pf08cert0803
Maximum Values:
Uo= 10,5v
Io= 13ma
Po= 34mw
Output:
Ac 253v 2a
126,5v 4a
500va
P.f. 0.7
Dc 40v 2a
80w
Um= Ac 253v
Dc 30v
10ma
Um= Dc 40v
Supply: Dc 20-30v/20-25ma
Um= Ac 253v/dc 125v
Ambient Temp: -20˚c Ta 60˚c
Control Dwg.: 116-0035
Sa Aus Ex 2244x
Ex(ia) I/iic (tamp= -20˚c To 60˚c)
Made In Singapore
Weight: 110 Gm
