Klockner Moeller Zm-25-pkz2 Overload Trip Module 690V 0.6-40A 50/60 Hz

Klockner Moeller Zm-25-pkz2 Overload Trip Module 690V 0.6-40A 50/60 Hz
Klockner Moeller
Pkz2
Zm-25-pkz2
16-25
I Greater Than 200-350
Ptb 3.53/38 8.299
Ui = 690V~
Ie = 0.6-40A
50/60 Hz
Iec 445
En 50005
Iec 157 / 158 / 292
Vde 0660 / 101 / 102 / 104
Nfc 63-110 / 120 / 650
Maximum Rated Voltage Is 600Y / 347V Ac
Max Rms Sym Amps
42Ka – 600V Ac
65Ka – 480V Ac
Use All 3 Phases
Trip Rating Is 125% Of Dial Setting
Tightening Torque: 16Lb.-in. / 1.8 Nm
Awg 14 – Awg 6
Cu And 75°C Wire Only
Made In Germany
Made In W.Germany
Weight: 730 Gm
